GEP-150-36

其他型号

GEP-75-90 GEP-80-42 GEP-100-36 GEP-100-42 GEP-100-54 GEP-100-90

Model List

Model	Rated power	Input voltage	Output voltage	Output current	Dimension	THD(Typ)	PF(Typ)
GEP-150-36	150W	100-277V	25-36V	4500mA±5%	1765836mm	<15%	>0.95

SAP

GEP

GEP-150-36

Input voltage: 100-277V

Output voltage: 25-36V

Performance parameters: THD<10%/PF>0.95

Surge protection: 4/6KV

IP grade: IP65

Protections: Input OVP, output SCP/OVP/OTP

Global certifications: CE

Warranty: 5 years

※Power will be off at 320V high voltage and resume after the voltage is normal

Advisory BACK

Related products： GEP-75-90 GEP-80-42 GEP-100-36 GEP-100-42 GEP-100-54

Model List

Model	Rated power	Input voltage	Output voltage	Output current	Dimension	THD(Typ)	PF(Typ)
GEP-150-36	150W	100-277V	25-36V	4500mA±5%	1765836mm	<15%	>0.95
