    HVE-30H-38*
    其他型号
    HVE-30H-38* HVE-30H-56* HVE-50H-38* HVE-50H-56* HVE-50H-72* HVE-75H-38*
    Model List
    ModelRated powerInput voltage

    Output voltag

    		Output currentDimensionTHD(Typ)PF(Typ)
    HAE-30H-38A30W200-277V20-38V300-1000mA
    		109*61*32.5mm<10%>0.95
    HAE-30H-38B200-277V20-38V300-1000mA109*61*32.5mm<10%>0.95

    A-Adjustable potentiometer version  B-3 in 1 dimming version



    HVE-30H SPEC _V1.0(EN).pdf


  • HVC系列
  • HBC系列
  • HVE系列
  • HAE系列
  • SAP
  • SCP系列
  • GEP

    HVE-30H-38*

    Input voltage: 200-277V

    Output voltage: 20-38V

    Performance parameters: THD<10%/PF>0.95

    Surge protection: 4/6KV

    IP grade: IP67

    Protections: Input UVP, output SCP/OVP/OTP

    Global certifications: CCC/CE

    Warranty: 5 years


    Advisory BACK
    Related products： HVE-30H-38* HVE-30H-56* HVE-50H-38* HVE-50H-56* HVE-50H-72*
    Model List
    ModelRated powerInput voltage

    Output voltag

    		Output currentDimensionTHD(Typ)PF(Typ)
    HAE-30H-38A30W200-277V20-38V300-1000mA
    		109*61*32.5mm<10%>0.95
    HAE-30H-38B200-277V20-38V300-1000mA109*61*32.5mm<10%>0.95

    A-Adjustable potentiometer version  B-3 in 1 dimming version



    HVE-30H SPEC _V1.0(EN).pdf
