    HVE-100H-38*
    其他型号
    HVE-30H-38* HVE-30H-56* HVE-50H-38* HVE-50H-56* HVE-50H-72* HVE-75H-38*
    Model List
    Model
    		Rated powerInput voltageOutput voltageOutput currentDimensionTHD(Typ)PF(Typ)
    HVE-100H-38A100W
    		200-277V
    		20-38V1900-3200mA155.5*61*32.5mm<10%>0.95
    HVE-100H-38B200-277V20-38V1900-3200mA155.5*61*32.5mm<10%>0.95




    HVE-100H SPEC_V2.0（EN）.pdf


  • HVC系列
  • HBC系列
  • HVE系列
  • HAE系列
  • SAP
  • SCP系列
  • GEP

    HVE-100H-38*

    Input voltage: 200-277V

    Output voltage: 20-38V

    Performance parameters: THD<10%/PF>0.95

    Surge protection: 6/10KV

    IP grade: IP67

    Protections: Input UVP, output SCP/OVP/OTP

    Global certifications: CCC/CE

    Warranty: 5 years


    Advisory BACK
    Related products： HVE-30H-38* HVE-30H-56* HVE-50H-38* HVE-50H-56* HVE-50H-72*
    Model List
    Model
    		Rated powerInput voltageOutput voltageOutput currentDimensionTHD(Typ)PF(Typ)
    HVE-100H-38A100W
    		200-277V
    		20-38V1900-3200mA155.5*61*32.5mm<10%>0.95
    HVE-100H-38B200-277V20-38V1900-3200mA155.5*61*32.5mm<10%>0.95




    HVE-100H SPEC_V2.0（EN）.pdf
