    GAE-50W600-87
    其他型号
    GAE-60W1A8-38 GAE-50W1A5-38 GAE-50W1A35-38 GAE-50W1A2-45 GAE-50W900-56 GAE-50W600-87
    Model List
    ModelRated powerInput voltage Output voltageOutput currentDimensionSurgePF(Typ)
    GAE-50W600-8750W100-277V54-87V600mA±5%113*37*28mm6kV>0.95



  • GPE
  • GSE
  • GAE series

    GAE-50W600-87

    Input voltage: 100-277V

    Protections: Input UVP/OVP, output OCP/SCP/OLP/OTP

    IP grade: IP65

    Warranty: 3 years

    ※GAE-50W input UVP/OVP :

    Power reduction at 100V low voltage and resumes operation after the voltage gets normal

    Power will be off at 325V high voltage and resumes operation after the voltage gets normal


    Advisory BACK
    Related products： GAE-50W600-87 GAE-50W900-56 GAE-50W1A2-45 GAE-50W1A35-38 GAE-50W1A5-38
    Model List
    ModelRated powerInput voltage Output voltageOutput currentDimensionSurgePF(Typ)
    GAE-50W600-8750W100-277V54-87V600mA±5%113*37*28mm6kV>0.95
