    GPE-50W1A35-38
    其他型号
    GPE-50I1A2-45 GPE-50I900-56 GPE-50W900-56 GPE-50W600-87 GEP-36W250-122 GPE-36W300-122
    Model List
    ModelRated powerInput voltageOutput voltage Output current  Dimension SurgePF(Typ)
    GPE-50W1A35-3850W100-277V22-38V1350mA±5%103*37*24mm4kV>0.95



    GPE-50W SPEC.pdf


  • GPE
  • GSE
  • GAE series

    GPE-50W1A35-38

    Input voltage: 100-277V

    Protections: Output OCP/SCP/OTP

    IP grade: IP65

    Warranty: 2 years

    ※ Power will be off at 325V high-voltage and resumes operation after the voltage is normal.


    Advisory BACK
    Related products： GPE-50W1A5-38 GPE-50W1A35-38 GPE-50W1A2-45 GPE-36W900-42 GPE-36W600-63
    Model List
    ModelRated powerInput voltageOutput voltage Output current  Dimension SurgePF(Typ)
    GPE-50W1A35-3850W100-277V22-38V1350mA±5%103*37*24mm4kV>0.95



    GPE-50W SPEC.pdf
