LBS-240W-260*

其他型号

LBS-40W-150* LBS-60W-150* LBS-80W-150* LBS-100W-150* LBS-120W-260* LBS-150W-260*

Model List

Model	Rated power	Input voltage	Output voltage	Constant powr voltage	Output current	Produst size	THD(Typ.)	PF(Typ.)
LBS-240W-260A	240W	120-277V	180-260V	200-260V	750-1200mA	1886137mm	<10%	>0.95
LBS-240W-260P		120-277V	180-260V	200-260V	750-1200mA	1886137mm	<10%	>0.95
LBS-240W-260L		120-277V	180-260V	200-260V	750-1200mA	1886137mm	<10%	>0.95

A: Adjustable potentiometer version

P: Off-line programming dimming version

L: Light controlled version

LBS-240W-260X SPEC_V1.0（EN）2024.6.20.pdf

LBS

LDS系列

LBS-240W-260*

Input voltage: 120-277V(Input voltage 100-120V, power decrease into 80%)

Output voltage: 180-260V

Electrical performance parameters:THD>10%/PF<0.95

Protections: Input UVP(power off when voltage<90V)/output SCP/OVP/OTP

Certifications: CB/CE/ENEC

Surge protection: 6/6KV

Efficiency: 94%

IP grade: IP42

5 years warranty

Remark:for build-in use only,lamp housing need to be waterproof

Advisory BACK

Related products： LBS-320W-260* LBS-240W-260* LBS-200W-260* LBS-150W-260* LBS-120W-260*

Model List

Model	Rated power	Input voltage	Output voltage	Constant powr voltage	Output current	Produst size	THD(Typ.)	PF(Typ.)
LBS-240W-260A	240W	120-277V	180-260V	200-260V	750-1200mA	1886137mm	<10%	>0.95
LBS-240W-260P		120-277V	180-260V	200-260V	750-1200mA	1886137mm	<10%	>0.95
LBS-240W-260L		120-277V	180-260V	200-260V	750-1200mA	1886137mm	<10%	>0.95

A: Adjustable potentiometer version

P: Off-line programming dimming version

L: Light controlled version

LBS-240W-260X SPEC_V1.0（EN）2024.6.20.pdf
