SAP-200W-56*

其他型号

SAP-240W-343* SAP-200W-286* SAP-150W-214* SAP-100W-143* SAP-240W-56* SAP-200W-56*

Model List

Model	Rated power	Input voltage	Output voltage	Output current	Size(MM)	THD	PF
SAP-200W-56A	200W	100-277V	27-56V	2500-4800mA	1866038	＜10%	＞0.95
SAP-200W-56B		100-277V	27-56V	2500-4800mA	1866038	＜10%	＞0.95
SAP-200W-56C		100-277V	27-56V	2500-4800mA	1866038	＜10%	＞0.95
SAP-200W-56P		100-277V	27-56V	2500-4800mA	1866038	＜10%	＞0.95

Version:

A-Adjustable potentiometer version

B-Three-in-one dimming version

C-12V auxiliary power version

P-Off-line programming dimming version

HVC系列

HBC系列

HVE系列

HAE系列

SAP

SCP系列

GEP

SAP-200W-56*

Input voltage: 100-277V

Output voltage: 27-56V

Performance parameters: THD<10%/PF>0.95

Protection level: 6/10KV

IP grade: IP65

Protections: Input OVP/UVP, output SCP/OTP/OVP/UVP

Global certifications: CCC/CE/CB

Warranty: 5 years

Input UVP: If the input voltage is lower than 90Vac, the power will be reduced by half; if the input voltage is lower than 80Vac, the power will be turned off, and the AC voltage will be restored after it returns to normal.

Input OVP: If the input voltage is higher than 330Vac, the power will be turned off, and the AC voltage will be restored after it returns to normal.
